Adhesive Log Roll 6 shaft slicing machine

Six Shaft Roll Slice Cutting Machine:

Trasy Enterprises is a machine manufacturing company from Mumbai, India. We also have a machine manufacturing unit in Kunshan, China. We make slice cutting machines for adhesive tapes from 1300mm width & 1600mm width. A range of Semi-automatic, Automatic and fully automatic slice cutting machines is the range of products.

This machine has six shafts log roll tape slice cutting machine. It has a turret exchange system, suitable for high-speed slice cutting log rolls of BOPP packing tape, PVC Insulation tape, Masking tape, Double-sided tape, Duct tape, Aluminium foil tape, etc.

This machine can cut the Max-width of 1300mm, Maximum diameter of the roll can be 140mm. The smallest possible width of cutting is 2mm. The Cutting Speed of the machine is about 35cuts/min. The cutting position accuracy is 50 microns. The inner diameter of the paper tube is 76mm. This is a very cost-effective high production machine.

Shaft motor drive AC-5HP+inverter(Mitsubishi) 1set/set

Blade motor(Stepless speed regulation ) AC-3HP+inverter(Mitsubishi) 1set/set

Change system Cylinder drive Positive and negative exchange type 1set

Dimension setting control 750w servo motor/drive(Mitsubishi) 1set/set

Cutting setting control 750w servo motor/drive(Mitsubishi) 1set/set

Blade angle setting control 100w servo motor/drive(Mitsubishi) 1set/set

Size/Cut part(screw rail) High precision(Taiwan ABB) 2sets

Automatic cooling system Water jet type 3sets

Shaft clip Automatic pneumatic type 6sets

Cutting shaft rear bracket Barometric swing (Automatic thimble) 3sets

Blade 160mm (Tungsten steel) 3sets

Cutting Shaft 76mm, 38mm each 6sets

Guide rail, lead screw lubricating system Manual oil feed type 2 set

Screen 10.2 inch LCD screen (kunlun) 1set/set

PLC control system Mitsubishi (50 sizes Record) 1set/set

Maintenance tools Deli brand 1set

PVC roll 76mm, 38mm each 10 sets
