slicing machine

Hot Melt Coater Specification: MELTACOATER 6” RTRMachine Type: Die CoatingMax. Size of coating : 100mm, GSM: 20 to 175, Max. Speed of coating : Speed 10 mpm at 50 GSMM/c specifications:1. Unwind: 1To hold 110 mm width Silicon paper.76 MM core ID.Powder Brake2. Coating Station:Slot Die coating synchronized line speed and gear pump with PLCAll metal rolls heated evenly.Accurate Temp. Control.All silicon rolls dynamic balanced.Back up roller Pneumatically operated.AC Drive for coating roller.3. Lamination Nip:Dynamic balanced Metal roll, Silicone rollOperation & pressure PneumaticAC Drive to the nip4. Renwind: To hold max. 110 mm width material.400 mm Dia. Max.76 MM core ID.Tapper tension controlled winding.AC Drive for controlled winding.5. Permelter:Tank capacity 5 Lit.Melting Capacity 5 Lit/hrDry tank capacity: 5 Lit.liquid tank capacity 0.5 Lit.Pump Capacity 0.5 Lit/MinAccurate Temp. Control.6. Hot melt HoseTo Supply 5 Kgs/hrLength 1 mAccurate Temp. Control.DIMENTIONS: 2x1.25x 1.5 mTotal Electrical Load : 8 KWWatch the machine in running: https://youtu.be/LeLSOluz7Ig

Hot melt Coating Machines HMC 6 PLC

INR 870000

Adhesive Log Roll 6 shaft slicing mach

INR 2130000

ApplicationCutting PVC Tape, OPP Tape, PE Tape, masking tape, double side tape, paper tape, fabric and etc.Machine Parameters:Max-width of Material 1300mmMax-diameter of Material 80mmMin-width of cutting 3mmCutting Speed 0-35cuts/minPositioning accuracy 0.05mmInner diameter of paper tube 38mmVoltage 415 V

Four Shaft Cutting Machine

INR 1410000

DESCRIPTION:Tape Slicing machine for masking tape, for BOPP tape, double side tape, kraft tape, cloth tape, foam tape.Characteristics:• HMI touch screen• PLC automation control system• Traverse stepping motor: 16NM• Transmission ball screw: 3210• Traverse track: 25*25mm• Feed servo motor: 1 (KW)• Bead screw drive :2510• Knife shifting circular rail: Ø30• Cylinder: 50×50 & 50×200• Solenoid valve: 4V24• Can be equipped with a round knife: Ø300• Maximum feed width: 1.35M• Maximum cutting diameter: 220mm• Minimum cutting width: 1mm• Positioning accuracy: ±0.05mm• Cutting shaft specifications: 3 inches• Dimensions: 2300*1000*1100mm• Voltage: 415 (V)• Weight: 360 (KG)• Total power: 4.8 (KW)

Automatic Tape Cutting Machine

INR 630000

Tape rewinding machine and Slicing machine for masking tape. For BOPP tape ,double side tape, masking tape, kraft tape, cloth tape, foam tape on all kinds of adhesive tape rewinding.Characteristics:1. Two-section of electronic counter to control the length of material accurately, Auto returning to zero.2. Magnetic powder type winding control; rewinding smoothly ; easy to control.3. Semi-Automatic Cutting machinery is used for the splitting of sticker, double-side tape, masking tape, BOPP tape and so on.4. Semi-Automatic Cutting Machine has pneumatic rotary blade for splitting, pneumatic disc feed and tail stock (the tail stock is designed with protection device for inadequate air pressure.), PE rubber tubes are designed on the main cutting shaft for disc protection so as to avoid damaging the blade. The precise splitting length depends on locating shafts, which is hexagonal shaft.Maximum width of the raw material: 1300 mmMaximum diameter of the raw material: 600 mmMinimum width of slitting: 3 mmThe diameter of the paper core: 3 inchWorking voltage: 415V 50HZPower: 1.5KW

Rewinding and Slicing Machine

INR 510000

Application: This four shaft auto cutting machine is also suitable for foam tape, electrical tape, duct tape, foil tape, double sided tape, masking tape, cloth tape, fabric tape, PVC tape, BOPP tape, PE tape, PET tape, kraft paper tape, cellophane tape etc Feature :1. Main driving part: Taiwan AC motor with inverter is employed.2. Central control unit: Programmable central control is used and 20 sizes can be set on the same shaft for auto transfer and cutting.3. Operating panel: All functions are operated on the 10

Adhesive Log Roll 4 shaft slicing mach

INR 1860000

Application:Suitable for different kind adhesive tapessuch as BOPP, foam tape, masking tape, duct tape,double sided tape,cloth tape,industrial tape, protection film, etc.Ideal for tape distributors and converters.Feature1. Main driving part: Taiwan AC motor with inverter is employed.2. Central control unit: programmable central control is used and 20 sizes can be set on the same shaft for auto transfer and cutting.3. Operating panel: all functions are operated on the 10.4

Single shaft auto roll cutting machine

INR 1230000

Application:It is used for the adhesive tape, protective film, fabric, non woven, so on roll stock materials. Feature:1. With full-manual cutting and simple operation, it has great cutting efficiency.2. Circular blade cutting and pneumatic blade feeding are employed to ensure smooth cutting surface.3. Its equipped with cutting width gauge for quick and stable positioning.4. With small volume and simple maintenance, it's economical and efficient. Main Technical Parameters:effective width 1300mm, 1600mmmax. cutting diameter 150mm other size as the customer request.we can made.cutting width 3-1600mmI.D. of paper core 3

SEMI AUTOMATIC TAPE SLICING MACHINE

INR 420000

Application:Suitable for different kind adhesive tapessuch as BOPP, foam tape, masking tape, duct tape,double sided tape,cloth tape,industrial tape, protection film, etc.Ideal for tape distributors and converters.Feature1. Main driving part: Taiwan AC motor with inverter is employed.2. Central control unit: programmable central control is used and 20 sizes can be set on the same shaft for auto transfer and cutting.3. Operating panel: all functions are operated on the 10.4

Tape Rewinding Machine

INR 600000

Filter using tags

Hot Melt Coater Specification: MELTACOATER 6” RTRMachine Type: Die CoatingMax. Size of coating : 100mm, GSM: 20 to 175, Max. Speed of coating : Speed 10 mpm at 50 GSMM/c specifications:1. Unwind: 1To hold 110 mm width Silicon paper.76 MM core ID.Powder Brake2. Coating Station:Slot Die coating synchronized line speed and gear pump with PLCAll metal rolls heated evenly.Accurate Temp. Control.All silicon rolls dynamic balanced.Back up roller Pneumatically operated.AC Drive for coating roller.3. Lamination Nip:Dynamic balanced Metal roll, Silicone rollOperation & pressure PneumaticAC Drive to the nip4. Renwind: To hold max. 110 mm width material.400 mm Dia. Max.76 MM core ID.Tapper tension controlled winding.AC Drive for controlled winding.5. Permelter:Tank capacity 5 Lit.Melting Capacity 5 Lit/hrDry tank capacity: 5 Lit.liquid tank capacity 0.5 Lit.Pump Capacity 0.5 Lit/MinAccurate Temp. Control.6. Hot melt HoseTo Supply 5 Kgs/hrLength 1 mAccurate Temp. Control.DIMENTIONS: 2x1.25x 1.5 mTotal Electrical Load : 8 KWWatch the machine in running: https://youtu.be/LeLSOluz7Ig

Hot melt Coating Machine

INR 870000

Adhesive Log Roll 6 shaf

INR 2130000

ApplicationCutting PVC Tape, OPP Tape, PE Tape, masking tape, double side tape, paper tape, fabric and etc.Machine Parameters:Max-width of Material 1300mmMax-diameter of Material 80mmMin-width of cutting 3mmCutting Speed 0-35cuts/minPositioning accuracy 0.05mmInner diameter of paper tube 38mmVoltage 415 V

Four Shaft Cutting Machi

INR 1410000

DESCRIPTION:Tape Slicing machine for masking tape, for BOPP tape, double side tape, kraft tape, cloth tape, foam tape.Characteristics:• HMI touch screen• PLC automation control system• Traverse stepping motor: 16NM• Transmission ball screw: 3210• Traverse track: 25*25mm• Feed servo motor: 1 (KW)• Bead screw drive :2510• Knife shifting circular rail: Ø30• Cylinder: 50×50 & 50×200• Solenoid valve: 4V24• Can be equipped with a round knife: Ø300• Maximum feed width: 1.35M• Maximum cutting diameter: 220mm• Minimum cutting width: 1mm• Positioning accuracy: ±0.05mm• Cutting shaft specifications: 3 inches• Dimensions: 2300*1000*1100mm• Voltage: 415 (V)• Weight: 360 (KG)• Total power: 4.8 (KW)

Automatic Tape Cutting M

INR 630000

Tape rewinding machine and Slicing machine for masking tape. For BOPP tape ,double side tape, masking tape, kraft tape, cloth tape, foam tape on all kinds of adhesive tape rewinding.Characteristics:1. Two-section of electronic counter to control the length of material accurately, Auto returning to zero.2. Magnetic powder type winding control; rewinding smoothly ; easy to control.3. Semi-Automatic Cutting machinery is used for the splitting of sticker, double-side tape, masking tape, BOPP tape and so on.4. Semi-Automatic Cutting Machine has pneumatic rotary blade for splitting, pneumatic disc feed and tail stock (the tail stock is designed with protection device for inadequate air pressure.), PE rubber tubes are designed on the main cutting shaft for disc protection so as to avoid damaging the blade. The precise splitting length depends on locating shafts, which is hexagonal shaft.Maximum width of the raw material: 1300 mmMaximum diameter of the raw material: 600 mmMinimum width of slitting: 3 mmThe diameter of the paper core: 3 inchWorking voltage: 415V 50HZPower: 1.5KW

Rewinding and Slicing Ma

INR 510000

Application: This four shaft auto cutting machine is also suitable for foam tape, electrical tape, duct tape, foil tape, double sided tape, masking tape, cloth tape, fabric tape, PVC tape, BOPP tape, PE tape, PET tape, kraft paper tape, cellophane tape etc Feature :1. Main driving part: Taiwan AC motor with inverter is employed.2. Central control unit: Programmable central control is used and 20 sizes can be set on the same shaft for auto transfer and cutting.3. Operating panel: All functions are operated on the 10

Adhesive Log Roll 4 shaf

INR 1860000

Application:Suitable for different kind adhesive tapessuch as BOPP, foam tape, masking tape, duct tape,double sided tape,cloth tape,industrial tape, protection film, etc.Ideal for tape distributors and converters.Feature1. Main driving part: Taiwan AC motor with inverter is employed.2. Central control unit: programmable central control is used and 20 sizes can be set on the same shaft for auto transfer and cutting.3. Operating panel: all functions are operated on the 10.4

Single shaft auto roll c

INR 1230000

Application:It is used for the adhesive tape, protective film, fabric, non woven, so on roll stock materials. Feature:1. With full-manual cutting and simple operation, it has great cutting efficiency.2. Circular blade cutting and pneumatic blade feeding are employed to ensure smooth cutting surface.3. Its equipped with cutting width gauge for quick and stable positioning.4. With small volume and simple maintenance, it's economical and efficient. Main Technical Parameters:effective width 1300mm, 1600mmmax. cutting diameter 150mm other size as the customer request.we can made.cutting width 3-1600mmI.D. of paper core 3

SEMI AUTOMATIC TAPE SLIC

INR 420000

Application:Suitable for different kind adhesive tapessuch as BOPP, foam tape, masking tape, duct tape,double sided tape,cloth tape,industrial tape, protection film, etc.Ideal for tape distributors and converters.Feature1. Main driving part: Taiwan AC motor with inverter is employed.2. Central control unit: programmable central control is used and 20 sizes can be set on the same shaft for auto transfer and cutting.3. Operating panel: all functions are operated on the 10.4

Tape Rewinding Machine

INR 600000
