Description

Application: Slitting BOPP Tape, PE Tape and etc. Machine Parameters: Max-width of loading jumbo 1600mm Max-diameter of loading jumbo 800mm Diameter max. of slit rolls 300mm (2 when shaft) Width min. of slit rolls 20mm Inner diameter of slit rolls 76.2mm(3 inches) Rewinding Speed 0-200m/min Voltage 415V Standard configuration Main motor(Taiwang Liangji ) AC-5HP Inverter（Mitsubishi） 1set Drive roller(knurling teflon) Dia:100mm 1 set Tension roller(knurling teflon) Dia.:101mm 1set Spread smooth roller Dia.:100mm 1set Rewinding shaft(Dedicated) Six line type(76mm) 8sets Polyurethane press roller Linear guideway push type 2sets Unwinding double roller Integrated 1set Roll change system Manual, automatic, point 1set Jumbo loading roller Air expanding shaft(76mm) 1set Transition roller Diameter:90mm 3sets Knurling transition roller Diameter:80mm 3sets Tension device(15kg break) Automatic 1set Rewinding tension(5kg cluth) Automatic 2sets PLC control with HMI 7 inches（Mitsubishi） 1 set Label stick system Manual, Automatic 1 set Waste recovery rewinder(with broken edge detection) Automatic screw(10000m changing) 1set Slitting blade Screw flat knife 1set Noise insulation cover Fully enclosed double-open type 1set Automatic tube wearing machine 2 sets of mould ） 1set Maintenance tools Deli 1set Watch Machne in working : https://youtu.be/sBt5ucrklyM
